ENGINE HOOD Geely Emgrand EC8
| № | Артикул | Название | IMG | QTY | Примечание |
|---|---|---|---|---|---|
| 1 | 101201365202 | ENGINE HOOD ASSY |
 |
1 | |
| 2 | 1012013670 | Петля капота левая |
|
1 | |
| 1012013671 | Петля капота правая |
|
1 | ||
| 3 | 1018010958 | UNLOCKING CABLE,ENGINE HOOD |
|
1 | |
| 4 | 1018010962 | ENGINE HOOD LOCK |
|
1 | |
| 5 | 1018010767 | LEFT AIR SPRING,ENGINE HOOD |
|
1 | |
| 1018012529 | RIGHT AIR SPRING,ENGINE HOOD |
|
1 | ||
| 6 | 1018011110 | LEFT SEAL,ENGINE COMPARTMENT |
|
1 | |
| 1018011111 | RIGHT SEAL,ENGINE COMPARTMENT |
|
1 | ||
| 7 | 1018009803 | UPPER TRIM,LEFT FENDER |
|
1 | |
| 1018009804 | UPPER TRIM,RIGHT FENDER |
|
1 | ||
| 8 | 1018008036 | SOUND INSULATOR,ENGINE HOOD |
|
1 | |
| 9 | 101801136696 | INNER SEAL,ENGINE HOOD |
|
1 | |
| 10 | 1018011109 | FRONT SEAL,ENGINE COMPARTMENT |
|
1 | |
| 11 | 1018008434 | UNLOCKING HANDLE,ENGINE HOOD |
|
1 | |
| 12 | JQ691C66 | E CLIP |
|
15 | |
| 13 | Q1840820 | HEXAGON BOLT WITH FLANGE M8X20 |
|
4 | |
| 14 | 1018006387 | AIR SPRING BOLT |
|
2 | |
| 15 | 5032001100 | ENGINE HOOD UPPERRUBBER CUSHION |
|
4 | |
| 16 | Q1840616TF2 | HEXAGON FLANGE BOLT |
|
3 | |
| 17 | Q1840820 | HEXAGON BOLT WITH FLANGE M8X20 |
|
4 | |
| 18 | 1067002364 | 1-WAY CLIP |
|
2 |
