Передняя дверь [RUSSIA, 4G1.8T, GL\G] Geely Atlas (NL-3)
| № | Артикул | Название | IMG | QTY | Примечание |
|---|---|---|---|---|---|
| 1 | 5075030600C15 | LF DOOR ASSY |
 |
1 | |
| 5075030500C15 | ASSY, RF DOOR INSTALLATION |
|
1 | ||
| 2 | 5075005500661 | RF DOORFRAME WEATHERSTRIP |
|
1 | |
| 5075005400661 | LF DOORFRAME WEATHERSTRIP |
|
1 | ||
| 3 | 5075005300661 | ASSY, RF DOOR WEATHERSTRIP |
|
1 | |
| 5075006000661 | ASSY, LF DOOR WEATHERSTRIP |
|
1 | ||
| 4 | 5075005200 | ASSY, REAR RAIL, RF DOOR GLASS |
|
1 | |
| 5075005100 | ASSY, REAR RAIL, LF DOOR GLASS |
|
1 | ||
| 5 | 5075005000661 | RF DOOR & FRAME TRIM |
|
1 | |
| 5075004900661 | QUARTER TRIM, LF DOOR WINDOW FRAME |
|
1 | ||
| 6 | 5075003100 | DOOR CUSHION |
|
2 | |
| 7 | 5075004800 | ASSY, UPPER HINGE, RF DOOR |
|
1 | |
| 5075004700 | ASSY, UPPER HINGE, LF DOOR |
|
1 | ||
| 8 | 5075004600 | RF DOOR LOWER HINGE ASSY |
|
1 | |
| 5075004500 | LF DOOR LOWER HINGE ASSY |
|
1 | ||
| 9 | 5075004400 | ASSY, FRONT DOOR CHECK |
|
1 | |
| 10 | JQ1670830TF6 | HEXAGON FLANGE BOLT |
|
4 | |
| 11 | Q32006F31 | HEXAGON FLANGE NUT |
|
2 | |
| 12 | JQ1840820F31S | HEX BOLT |
|
1 | |
| 13 | 5081005600 | 3 DOOR DAMPING PLATE |
|
1 | |
| 14 | Q32006F31 | HEXAGON FLANGE NUT |
|
2 | |
| 15 | Q1840820TF6 | HEXAGON FLANGE BOLT |
|
4 | |
| 16 | 5075004000 | PROTUCTING NUT, DOOR HINGE MOUNTING SCREW |
|
2 | |
| 17 | 5075005800 | 2 DOOR DAMPING PLATE |
|
1 |
